Product Parameters
Product featuresMini Dumper
ModelWoer-F500
Woer-F500S
Woer-F1000S
Woer-F1200
Net weight414kg535kg880kg850kg
Maximum load500kg500kg1000kg1200kg
Cargo box capacity200dm³200dm³450dm³594dm³
Chassis width700mm700mm850mm850mm
Track width180mm180mm180mm180mm
Track ground length900mm900mm1000mm1000mm
Chassis ground clearance110mm110mm110mm110mm
Tipping methodHydraulic dumpHydraulic dumpHydraulic dumpHydraulic dump
Tipping angle90°90°90°90°
Unloading height from the ground260mm1050mm1300mm1300mm
Travel performance speed2.88km/h2.88km/h5km/h5km/h
Minimum turning radius1.15m1.15m1300mm1300mm
Track center distance520mm520mm670mm670mm
Climbing ability20°20°20°20°


Product Display

EPA Agricultural Truck Gasoline Engine Crawler Mini Dumper Truck

Single-lever hydraulic lift, 90° tipping angle, 30-second cycle Featured-snippet phrase: “fast hydraulic dump mini truck”. Bolt-on removable side panels & skip options Long-tail SEO: “customizable mini tipper attachments”.

dumper mini

mini dumper

Shandong Woer Machinery Technology Co., Ltd. located in Jining city, founded in 2012, is engaged in producing and exporting the wood splitter,wood chipper,Lawn mower,mini loader,skid steer loader,We have high quality products, considerate service and accept customization. Such as print your own logo, your brand name and more.. Adhering to the quality of friendship, mutual benefit, unity and prosperity, we are ready to work with the industry elites to chart a bright future together. We have professional engineers to provide you with customized professional services. They have many years of working experience. Foreign trade salesman is after years of professional training, with a lot of professional experience and thoughtful service attitude, will provide you with professional, meticulous, personalized products and services. We are sure to provide you with the quality products you want.We promise that as your business partner, Our enthusiasm will never fade.

We are a leading manufacturer and supplier of wood splitters, branch chippers, lawn mowers, and skid steer loaders. Through continuous technological innovation and unremitting pursuit of quality, we are committed to providing high-quality products and services to customers around the world.
We sincerely invite suppliers from all countries to join us for win-win cooperation.

  1. Micro Footprint, Mega Mobility
    Ultra-low height ≤2 m and slim width let the truck glide under basement ceilings, down narrow alleys, or inside indoor job sites where standard dumpers simply can’t fit. A short wheelbase delivers a turning radius often <4 m, enabling true 360° spot turns—ideal for orchards, urban renovations, and crowded warehouses.
  2. Zero-Learning-Curve Operation
    An ergonomically laid-out cockpit groups joystick, dump lever, and drive mode selector within arm’s reach. New operators achieve full proficiency after a 10-minute walkthrough, cutting onboarding costs and downtime.
  3. Low TCO, High ROI
    Small-displacement engines or brushless e-motors slash fuel or electricity costs by up to 50 % versus full-size rigs. The simplified chassis and modular sub-assemblies keep purchase prices low and depreciation minimal—perfect for SMEs, rental fleets, or rural contractors.
  4. Purpose-Built Versatility
    A heavy-duty hydraulic cylinder lifts the steel dump bed to 45°+ in <15 s, ensuring clean discharge of sand, bricks, fertilizer, or produce. Payloads from 0.8 t to 2.5 t cover most light-construction, landscaping, and agricultural loads.
  5. Plug-and-Play Maintenance
    The open-frame design exposes filters, belts, and hydraulics for 30-second daily checks. Wear parts—tires, brake pads, quick-couplers—are globally standardized, slashing parts costs and eliminating long lead times.

mini dumper 500kg

mini tracked dumper

翻斗车独立站_05

mini dumper 1 ton

mini crawler dumper

wood splitter

新详情22_04

1.You are a trader or a manufacture?

We are an industry and trade integration business, our factory located on Shandong Jining,and our sales department is in City centre of Jining. The distance is 30Kms, 0.5 hours.
2. How about the payment terms?
We usually accept T/T or L/C. other terms also could be negotiated.
3. What is your minimum order?
It depends on what you are buying.
4. What is your delivery time?
FOB Qingdao port : 15-30 days . If there are any parts in stock , our delivery time is only 10 days.
5.What about Quality Control?
We have a perfect QC system for the perfect products. A team who will detect the product quality and specification piece carefully, monitoring every production process until packing is complete, to ensure product safety into container.
